Economy Roller Apparatus 230v 2 Position w/ All Position Drive SKU: 7622-01220


SKU: 7622-01220 Categories: ,


The Bellco Economy Roller Apparatus is a variable speed two or four bottle roller apparatus used for the purpose of producing animal cells or cell products.  This small sized unit is ideal for experimental and pilot-scale cell culture.  Methods developed on this unit can easily be scaled up using the same technology to production sized units with a capacity of 90, 100 or 172 bottles.  Bellco’s full size modular units can be increased in capacity in 10 bottle increments as well. The unit features a heavy-duty DC motor and solid-state electronics for reliable operation.  The unit includes All-Position Drive belts so that every roller rotates, thus preventing slippage of light-weight plastic bottles.  An analog tachometer displays bottle speed.  Bellco’s unique hex-shaped shafts prevent roller slippage and produce positive drive.


  • Electrical Rating: 230 +/- 10 Vac @ 50/60 Hz Line Voltage, 0.5 Amp @ 230v, 50 Hz Power Consumption.
  • Dimensions: 14″W X 12.8″D X 7.4″H (36X33X19cm), 14″W X 12.8″D X 10.3″H (36X33X26cm) With Bottles.
  • Weight: 16 Lbs (7.3 Kg)
  • Bottle Speed: 0.25 – 3.0 Rpm
  • Environmental Conditions (OPERATING): Indoor Use, Pollution Degree 2, 4° To 50° C, Relative Humidity 0-90%, Non-Condensing.
  • Environmental Conditions (NON-OPERATING): –10° To 60° C, Relative Humidity 95% Maximum.

Additional information

Weight 500 oz
Dimensions 27 × 27 × 27 in
