80 Cu. Foot CO2 Incubator Extra Large Capacity SKU: 7728-S0256

SKU: 7728-S0256 Category:


Bellco CO2 Incubators have 80 cubic feet of volume and are designed for use with Bellco’s Extra Large Capacity Cell Production Roller Apparatus. Multiple internal convenience outlets allow simple connection to internally placed appliances such as CPRA, Roller Drums, Magnetic Stirrers, etc. Fans take air from the chamber top, pass it over two 1100 watt heaters and re-inject it into the chamber on the back wall. A touchscreen temperature and CO2 controller allows simple setting and monitoring of chamber temperature. A safety thermostat is included to prevent over-temperature failures. Shelf brackets are included for mounting of optional shelves.

7728-S0256 115 +/-10VAC, 50/60 Hz Line Voltage, 30 Amp (INCLUDES 3 AMP CONVENIENCE OUTLET LOAD)
DIMENSIONS: Exterior: 55″W X 43″D X 88″H (139.7 X 109.2 X 223.5cm)
Interior: 49″W X 35″D X 81″H (124.5 X 88.9 X 205.7cm)
Volume: 80 cubic ft. (2265 L)
Temperature Control Range: ambient +9oC to 50oC
Temperature Uniformity: +/-1.0o @ 37°C
CO2 Range: 0 – 20% concentration
Output: 4 – 20 mA
